RZR XP® 1000
XTREME POWER NEVER LOOKED THIS GOOD
64" Width. 110 HP. 29" Tires. 20" Usable Travel. This model is cut more aggressively and comes equipped with a refined cockpit to crush any terrain.
White Lightning
RZR XP® 1000
- ProStar HD 999 Motor
- 64" Width
- 21"/21" Travel
- Walker Evans® Needle Shocks
- 29" Maxxis® Big Horn Tires
- 13.5" Ground Clearance
THE DRIVING FORCE IN OFF-ROAD
ULTIMATE COMBINATION OF POWER, SUSPENSION & AGILITY
Through relentless innovation and a passion for the ride, RZR is the world-leader in off-road domination. There's more to achieving the pinnacle of Xtreme Performance than simply developing around just power or big travel. Each RZR is extensively engineered to deliver an optimally balanced chassis, and the ultimate combination of power, suspension & agility.
ALL NEW DESIGN
INSIDE & OUT
Inside the dark heart of the beast, the entire cockpit has been re-engineered – instinctive in nature, intuitive in control, and purposeful in detail.
- Premium Painted Panels
- Menacing LED Lighting
- Digital Display Cluster
- Redesigned Interior
- Lower Doors
NASTY OUTSIDE
NICE INSIDE
PRIMAL ILLUMINATION
FEEL THE FURY
PROSTAR ENGINE
The heart and soul of RZR XP 1000 is a menacing ProStar 1000 engine, pumping out a heavy motor and low-end forceful torque waiting to be unleashed with instant delivery. Launch into an accelerated blur, to hear the deep throaty roar that is only matched by its raw, visceral force.
CONTROLLED CHAOS
CLASS LEADING SUSPENSION
The intense interaction between vehicle and terrain can be nothing short of ruthless. Rocks, stumps, silt sand, mud, all being encountered at high-speed. This unrelenting onslaught is tamed with industry-leading suspension for unmatched control, confidence, and comfort. With an incredible 21" of usable travel and stage-tuned Walker Evans Needle Shocks, the race proven design has earned countless victories in the most rugged places on earth.
INSTINCTIVE CONTROL
INDUSTRY LEADING AGILITY
RZR industry-leading Agility is no accident. Our engineers developed the ultimate combination of chassis, suspension, steering geometry, AWD, and power to create an off-road vehicle with a level of high-performance handling and agility so responsive, it practically reads your mind.
ENGINE & DRIVETRAIN
| Engine Type | 4-Stroke DOHC Twin Cylinder |
| Cylinders-Displacement (cc) | 999 cc / 110 HP |
| Fuel System | Electronic Fuel Injection |
| Transmission/Final Drive | Automatic PVT P/R/N/L/H |
| Drive System Type | High Performance True On-Demand AWD/2WD |
| Cooling | Liquid |
Suspension
| Front Suspension | Dual A-Arm with Stabilizer Bar and 50.8 cm Usable Travel, 40.6 cm of Wheel Travel |
| Rear Suspension | Trailing Arm with Stabilizer Bar and 50.8 cm Usable Travel, 45.7 cm of Wheel Travel |
Brakes
| Front/Rear Brakes | 4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers |
| Parking Brake | Park in Transmission |
Tyres / Wheels
| Front Tyres | 29 x 9-14; Maxxis Bighorn |
| Rear Tyres | 29 x 11-14; Maxxis Bighorn |
| Wheels | Cast Aluminum |
DIMENSIONS
| Bed Box Dimensions (L x W x H) | 72.0 x 57.0 x 17.8 cm |
| Front/Rear Rack or Box Capacity | N/A kg / 136.1 kg |
| Fuel Capacity | 35.9 L |
| Ground Clearance | 35.6 cm |
| Overall Vehicle Size (L x W x H) | 302.2 x 162.6 x 187.3 cm |
| Wheelbase | 228.6 cm |
| Estimated Dry Weight | 658 kg |
Features
| Seat Height | N/A |
| Cargo System | Lock & Ride® |
| Hitch Towing Rating | N/A |
| Hitch/Type | Not Equipped |
| Instrumentation | Dual-sweep Analog Dials w/ 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, DC Outlet |
| Variants | Off-Road |
