RANGER® 1000 EPS
THE NEXT GENERATION OF WORLD'S BEST-SELLING UTV
We took the best-selling RANGER of all time, the RANGER XP 900, and gave it the capability to haul more, tow more and last longer while delivering more comfort, more convenience and more value for your hard-earned dollar.
Ranger® 1000 EPS
- Electronic Power Steering
- Lock & Ride Cargo System
- 1,500 lb Payload Capacity
- Stamped Steel Wheels
- Base Steel Bumper with Plow and Winch Integration
Ranger® 1000 EPS Premium
- Electronic Power Steering
- Adjustable Seat Slider
- Premium Automotive Paint
- 26 in. PXT 2 Tires
- 1,500 lb Payload Capacity
- Aluminum Black Xcelerator Wheels
HAUL HEAVY LOADS FOR BIG JOBS
Designed to handle a class-leading 2,500 lb towing capacity and industry-leading 1,000 lb box capacity, plus an impressive 1,500 lb payload capacity, the RANGER 1000 is your trusted partner for big jobs.
*Model shown with optional extra accessories
DEEPER BOX
Our deepest cargo box yet lets you confidently haul up to an industry-leading 1,000 lb and has 10% more cargo box volume*.
*Model shown with optional extra accessories
INNOVATIVE STORAGE
UNDER-SEAT STORAGE
CONFIDENTLY CLEAR CORNERS
An 8% tighter turning radius* enhances maneuverability in narrow or compact spaces.
*Model shown with optional extra accessories
EASY ON TURF
COMFORT YOU CAN FEEL
EASY ENTRY AND EXIT
Enjoy easy entry and exit with 5" more room* and improved ergonomics.
*Model shown with optional extra accessories
SMOOTH FROM THE START
All-new Pro-PVTi clutch delivers ultra-smooth engagement, drivability at low speeds and improved durability with sealed bushings and bearings.
*Model shown with optional extra accessories
DEFINITIVE TRACTION
The all-new PXT 2 tires bring you a new tread pattern for better grippage on any terrain.
*Model shown with optional extra accessories
PROTECTION IN TOUGH TERRAINS
The durable full under-body skid-plate fends off rocks and unsuspecting objects, while the large, steel front bumper provides coverage to the front end of the machine.
*Model shown with optional extra accessories
BRILLIANT LIGHTING
New headlights deliver a stronger light output extending your work day.
*Model shown with optional extra accessories
| Ranger 1000 EPS | Ranger 1000 EPS Premium |
ENGINE & DRIVETRAIN
| Engine Type | 4-Stroke SOHC Twin Cylinder | 4-Stroke SOHC Twin Cylinder |
| Cylinders-Displacement (cc) | 999cc | 999cc |
| Fuel System/Battery | Electronic Fuel Injection | Electronic Fuel Injection |
| Cooling | Liquid | Liquid |
| Transmission/Final Drive | Automatic PVT H/L/N/R/P; Shaft | Automatic PVT H/L/N/R/P; Shaft |
| Drive System Type | High Performance On-Demand True AWD/2WD/VersaTrac Turf Mode | High Performance On-Demand True AWD/2WD/VersaTrac Turf Mode |
| Engine Braking System/Active Descent Control | Not Equipped / Not Equipped | Not Equipped / Not Equipped |
Suspension
| Front Suspension | Dual A-Arm 25.4 cm Travel | Dual A-Arm 25.4 cm Travel |
| Rear Suspension | Dual A-Arm, IRS 25.4 cm Travel | Dual A-Arm, IRS 25.4 cm Travel |
Brakes
| Front/Rear Brakes | 4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers | 4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers |
| Parking Brake | Park in Transmission | Park in Transmission |
Tyres / Wheels
| Front Tyres | 25 x 10 -12; 489 | 26 x 9-12; PXT 2.0 |
| Rear Tyres | 25 x 11-12; 489 | 26 x 11-12; PXT 2.0 |
| Wheels | Stamped Steel | Aluminum Black Xcelerator 2.0 |
DIMENSIONS
| Wheelbase | 206 cm | 206 cm |
| Estimated Dry Weight | 693 kg | 697 kg |
| Overall Vehicle Size (L x W x H) | 305 cm x 158 cm x 193 cm | 305 cm x 158 cm x 193 cm |
| Ground Clearance | 30.5 cm | 30.5 cm |
| Seating Capacity | 3 | 3 |
| Fuel Capacity | 43 L | 43 L |
| Bed Box Dimensions (L x W x H) | 93.3 cm x 137.8 cm x 31.75 cm | 93.3 cm x 137.8 cm x 31.75 cm |
| Front/Rear Rack or Box Capacity | N/A / 453.6 kg | N.A / 453.6 kg |
| Payload Capacity | 680.4 kg | 680.4 kg |
| Hitch Towing Rating | 1,133.9 kg | 1,133.9 kg |
| Hitch/Type | Standard 5 cm Receiver | Standard 5 cm Receiver |
Features
| Cargo System | Lock & Ride® | Lock & Ride® |
| Lighting | 55W low/ 60W high, LED Tail | 55W low/ 60W high, LED Tail |
| Electronic Power Steering | Standard | Standard |
| Adjustable Driver's Seat | Not Eqipped | Standard |
| Tilt Steering | Standard | Standard |
| Instrumentation | 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder, DC Outlet | 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder, DC Outlet |
| Other Standard Features | Polaris Pulse Electrical System (3 position) | Polaris Pulse Electrical System (3 position) |
| Colours | Solar Red | Matter Titanium |
