PRO XD™
INDUSTRY-LEADING FEATURES
Industry-Leading Diesel Utility Vehicles Built to Withstand The Tough Duty Cycles And Usage on The Worksite - The New Work UTV Standard
Polaris® Pro XD ™ 2000D AWD
- Kubota 24HP Diesel Motor with 200 Hour Engine Service Interval
- Speed Limited
- Kevlar®- Backed Vinyl Seats
- Heavy-Duty Jobsite Tires
Polaris® Pro XD ™ 4000D AWD
- Kubota 24HP Diesel Motor with 200 Hour Engine Service Interval
- Speed Limited
- Kevlar®- Backed Vinyl Seats
- Heavy-Duty Jobsite Tires
INDUSTRY-LEADING DURABILITY
The Polaris PRO XD was designed with heavy-duty component to provide industry-leading durability.
KUBOTA 902 DIESEL
Industry-recommended 24 Horsepower Diesel engine
TOWING AND PAYLOAD
Industry-leading 2,500 pounds towing and 1,900 pounds payload
DRIVELINE COMPONENTS
Heavy-duty drive shaft, CVT boots and wheel bearings increase life expectancy
HEAVY-DUTY SEATS
All-new seats help resist punctures and tears
JOBSITE TIRES
All-new jobsite tires designed for longer life on hard-packed surfaces
HEAVY-DUTY POLY BED
Rust-free, dent-free bed with 1,250 pound capacity
INDUSTRY-LEADING SERVICEABILITY
The Polaris PRO XD has multiple industry-leading features to improve serviceability.
WARNING ALARMS
Vehicle fault alarms to notify users of potential issues that could cause serious damage to the vehicle. Alarms include low oil pressure, parking brake engagement, belt slip, and engine overheat
RELOCATED OIL DIPSTICK AND AIR FILTER
Easily conduct maintenance checks without having to raise the cargo bed
200-HOUR MAINTENANCE INTERVALS
Industry's longest certified maintenance interval in its class for less in-field maintenance
FRONT AIR INTAKE
Improved air filter life and consistent engine performance
INDUSTRY-LEADING SAFETY FEATURES
With safety being top priority on the jobsite, the PRO XD delivers industry-leading standard features designed to improve jobsite safety
ORANGE SEATBELTS AND DECALS FOR HIGH VISIBILITY
Orange seatbelts and vehicle decals improve visibility to the vehicle and surrounding workers
STANDARD FACTORY-INSTALLED ACCESSORIES
Back up alarm, horn and mechanical parking brake come standard
SPEED LIMITED
Top speed of 26 mph for jobsite compliance, with option to further limit speed down to 15 mph
TIGHT SEALING CAB
The PRO XD and cab were engineered together to create the tightest seal possible, keeping harmful dust and weather out. Click here for more cab information.
| PRO XD 2000D AWD | PRO XD 4000D AWD CREW |
ENGINE & DRIVETRAIN
| Engine Type | 3-Cylinder Kubota® Diesel | 3-Cylinder Kubota® Diesel |
| Cylinders-Displacement (cc) | 898cc | 898cc |
| Fuel System | Mechanical Injection | Mechanical Injection |
| Cooling | Liquid | Liquid |
| Transmission/Final Drive | Automatic PVT H/L/N/R/P; Shaft | Automatic PVT H/L/N/R/P; Shaft |
| Drive System Type | Not Equipped / Not Equipped | Not Equipped / Not Equipped |
| Engine Braking System/Active Descent Control | Standard | Standard |
Suspension
| Front Suspension | 22.9 cm | 22.9 cm |
| Rear Suspension | 22.9 cm | 22.9 cm |
Brakes
| Front/Rear Brakes | 4-Wheel Hydraulic Disc with Dual-Bore Front Calipers | 4-Wheel Hydraulic Disc with Dual-Bore Front Calipers |
| Parking Brake | Park in Transmission + Separate Mechanical Parking Brake Standard | Park in Transmission + Separate Mechanical Parking Brake Standard |
Tyres / Wheels
| Front Tyres | 26 x 10-12 Duro® DI-2042 Power Grip (M/T) | 26 x 10-12 Duro® DI-2042 Power Grip (M/T) |
| Rear Tyres | 26 x 10-12 Duro® DI-2042 Power Grip (M/T) | 26 x 10-12 Duro® DI-2042 Power Grip (M/T) |
| Wheels | 12 x 6 HD Steel - Gloss Black | 12 x 6 HD Steel - Gloss Black |
DIMENSIONS
| Wheelbase | 215.9 cm | 297.2 cm |
| Estimated Dry Weight | 723 kg | 873 kg |
| Overall Vehicle Size (L x W x H) | 320 x 159 x 191 cm | 399 x 159 x 191 cm |
| Ground Clearance | 27.9 cm | 27.9 cm |
| Seating Capacity | 2 | 4 |
| Fuel Capacity | 43.5 L | 43.5 L |
| Rear Box Dimensions (L x W x H) | 110.5 x 137 x 29 cm | 110.5 x 137 x 29 cm |
| Front/Rear Rack or Box Capacity | 567 kg | 567 kg |
| Payload Capacity | 862 kg | 941 kg |
| Hitch Towing Rating | 1,133.9 kg | 1,133.9 kg |
| Hitch/Type | Standard 5 cm Receiver | Standard 5 cm Receiver |
Features
| Cargo System | Lock & Ride® | Lock & Ride® |
| Lighting | 55W low / 60W high, LED Tail | 55W low/ 60W high, LED Tail |
| Electronic Power Steering | Not Equipped | Standard |
| Adjustable Driver's Seat | Not Equipped | Not Equipped |
| Tilt Steering | Standard | Standard |
| Instrumentation | All Digital Gauge, Speedomoter, Odometer, Tachometer, 2 Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, Engine Temperature, Hi-Temp Light, Clock, Clutch Belt Slip Warning, Glow Plug Indicator, Low Oil Pressure Indicator, Seat Belt Indicator, Parking Brake Engaged Alarm | All Digital Gauge, Speedomoter, Odometer, Tachometer, 2 Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, Engine Temperature, Hi-Temp Light, Clock, Clutch Belt Slip Warning, Glow Plug Indicator, Low Oil Pressure Indicator, Seat Belt Indicator, Parking Brake Engaged Alarm |
| Other Standard Features | Horn, Backup Alarm, Kevlar backed vinyl seat covering | Horn, Backup Alarm, Kevlar backed vinyl seat covering |
| Colours | Grey | Grey |
